Acrel AKH-0.66/K Ct Split Core Current Transformer Electricity Current Transformer Clamp On 150/5A Rs485 Ct

Name: Acrel AKH066K Ct Split Core Current Transformer Electricity Current Transformer Clamp On 1505A Rs485 Ct
Brand: Acrel
Price: 1 USD

Brand Name : Acrel

Model Number : AKH-0.66/K-Φ

Certification : CE

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T

Supply Ability : 5000pc/day

Delivery Time : 5-8 work days

Packaging Details : carton

Product name : Split Core Current Transformer

Rated primary current : Ranging up to 1000A

Certificate : CE ROHS UL

Rated secoundary current : 1/5A

Accuracy : 0.5

Contact Now

AKH-0.66/K ct split core current transformer

Product feature

The product has beautiful appearance, convenient installation and wiring, and is mainly used for power operation and maintenance and electricity transformation projects. The general output is AC 5A standard signal, which has the advantages of small size, high precision, strong load capacity and convenient installation. Save manpower, material and financial resources and improve efficiency for user transformation projects.

Parameters

Type	Ratio(A)	Precision degree and corresponding rated load (VA)		Circle	Hole Size(mm)	Voltage
K-Φ24	(150-200)/5		1	1	Φ24	3kV
K-Φ24	(250-300)/5		1.5		Φ24
K-Φ36	(300-400)/5		1.5		Φ36
K-Φ36	(500-600)/5	1.5			Φ36
K-Φ50	500A/5(1)A	1.5		1	Φ50
	(600-700)A/5(1)A	2.5		1
	(800-900)A/5(1)A	5		1
	1000A/5(1)A	10		1
